Modular Hose Ramp – Bridge Section with 2 x 185 mm Channels

This central steel bridge section is the heart of the modular ramp system and accommodates large hoses up to 185 mm in diameter. With two 185 x 185 mm channels, it carries two hoses or cables at once. Made from 7 mm thick galvanized steel finished in red powder coat (RAL 3020), it measures 370 x 400 x 190 mm and weighs about 41.5 kg. It supports 12 tonnes per vehicle axle. Together with the rubber sections, a 3400 mm long ramp can be built so most vehicles can cross without grounding. It must not be used with forklifts or vehicles with solid tyres.
